6100 Wood Boiler Specifications:
• 51" x 26" x 28" (HxWxD)
• 41.25" Flue Center To Ground
• 1/4" and 5/16" Steel Construction
• Quality Powder Coated Finish
• (2) Cast Iron Stationary Grates
• 50 cfm Forced Draft Fan
• Auto Damper Shutoff
• 4.75 Cu ft Firebox Capacity


• 28 Gallon Water Capacity
• 10" x 14" Fuel Door
• 5" x 7" Ash Removal Door
• 20" Log Length
• (8) 9"x4.5"x1.25" Firebricks
• 6" Flue
• 1-1/4" FNPT Connections
• 530 lbs (approximate)
